VINcoSIM - The Integrated Simulation Environment

VINcoSIM is a web-based integrated simulation environment to simulate junction temperatures and loss for Vincotech power modules. The software is designed to choose operation conditions as voltages, currents and switching frequencies to give a good fitting to the operation of the power module in real applications. All power loss and temperature calculations are based on real measurements taken of each module.

How does it work?

❶ Search our products database

❷ Select a product

❸ Run your simulation online

Why use VINcoSIM?

✓ It is accurate

We use real measurement data, all topologies are available, heatsink option is included.

✓ It is fast and complete

The procedure takes only seconds and the results reveal a lot of data in one glance.

✓ It is easy to use

Only 1 configuration step is needed, flexible options for your needs, no downloading necessary, no cost.

Simulate every module with every topology

VINcoSIM is based on a unique simulation core which offers the possibility to simulate every module with every topology. Adding new modules and even increasing the number of simulation methods was never easier. PLECS support is included.

More on the technical background:
VINcoSIM: Web-Based Electrothermal Simulation Case Study by IncQuery Group
(incquery-group.com)

Login or register

To execute simulations with VINcoSIM a registration is necessary.

First time users, continue to the registration form.

Visitors already registered, log in with your email address.

Knowledge Hub

Tutorials

Part 1 - Basics

Instructions of how to start a simulation and what to do with the set-up. See what the simulation summary includes.

Watch Video
Part 2 – Advanced features

Learn how to set up your heatsink definition.

Watch Video
Part 3 – Advanced features

Learn more about the features of the simulation result

Watch Video

Webinar - available on-demand

VINcoSIM webinar - The Next Generation Simulation Environment for Power Modules from Vincotech

Key takeaways:

Get to know a new user-friendly, web-based simulation environment
Learn how to solve your application-specific challenges for power modules
See real life examples in the simulation software
Discover the technical background of the simulation system and how it benefits you

Sign up now

PLECS support

Vincotech has assembled a PLECS library of individual functional topologies that customers can use to reconstruct power modules. These functional topologies are also available in VINcoSIM, which ensures compatibility with PLECS in terms of simulation results.
