An Easier Way to Catch Some Rays
With the latest addition to Vincotech‘s line of easy-to-use-modules, developing your next single-phase solar application has become even easier. These new flowSOL 1 BI (TL) modules pair a highly efficient H6.5 inverter with a dual booster for higher-power multi-PV panel installations. Engineered for applications up to 10 kW, the 50 A and 75 A flowSOL 1 BI (TL) modules are housed in a 12 mm, low-inductive flow 1 package.
Features:
- Booster + H6.5 topology
- Kelvin Emitter for improved switching performance
- Temperature sensor
- IGBT S5 chip-technology for high speed and smooth switching
- Low gate charge
- Very low collector emitter saturation voltage
Schematics
Main benefits:
- Optimized for single-phase solar applications
- Highly efficient, three-level H6.5 topology maximizes ROI
- Less filtering and cooling means lower system costs
- Compact, integrated solution reduces weight and increases power density
- Innovative royalty free H6.5 topology reduces power losses by up to 20%
- Highly integrated module drastically cuts design time compared to discrete or multiple module solutions
Samples of the flowSOL 1 BI (TL) modules are available through our usual channels.
- Vincotech_PR-18-04_flowSOL-1-BI-TL.pdf – PDF, 211 KB
